Frameless Eaves Rooflight
Frameless Eaves Rooflight
The Glideline Frameless Eaves Rooflight creates a striking glass connection between roof and wall, delivering uninterrupted views and a seamless flow of natural light.
Frameless link between roof and walls
Bonded glass-to-glass joints with minimal frame
Safe, secure and weather resistant
Get your quote:
mm x mm
1. Width: Measure horizontally across the opening from edge to edge at the top, middle, and bottom. Use the smallest measurement.
2. Length: To measure the length, take measurements from end to end along the longest side. If there are variations, measure at multiple points and use the longest measurement to ensure accuracy.
With Sill
1. Width: Measure horizontally across the opening from edge to edge at the top, middle, and bottom. Use the smallest measurement.
2. Length: To measure the length, take measurements from end to end along the longest side. If there are variations, measure at multiple points and use the longest measurement to ensure accuracy.
Black
1. Width: Measure horizontally across the opening from edge to edge at the top, middle, and bottom. Use the smallest measurement.
2. Length: To measure the length, take measurements from end to end along the longest side. If there are variations, measure at multiple points and use the longest measurement to ensure accuracy.
Need to talk to an expert? Get in touch
Overview
Seamless Roof-to-Wall Design
Combines roof and vertical glazing to maximise light and connect spaces without visible framing.
Slim Glass-to-Glass Joints
Smallest visible sightlines create a sleek finish and flood interiors with natural light.
Thermally Efficient Glazing
Highly insualted with low U-values and high performance safetey glass.
Weatherproof and Secure
Double or triple glazing, bonded joints and weather resistant throughout.
Customisable Glazing Options
Add solar control or self-cleaning glass for performance tailored to your project.
Simple, Clean Installation
Delivered in pre-prepared units with minimal on-site sealing for faster fitting and cleaner results.
.png)
Architectural Glazing for Light, Space and Simplicity
Visually appealing and technically superior, Frameless Eaves Rooflights are the ideal solution for creating distinctive glass focial points in any room, with an uninterrupted transition from the roof to the wall.
With no internal framing and a fully bonded edge-to-edge finish, these rooflights introduce more daylight, eliminate bulky junctions, and support a modern open-plan layout with clarity and confidence.
.png)
Manufactured to Perform in All Seasons
Using high-spec aluminium and factory-bonded glazing, each Glideline Eaves Rooflight is engineered for comfort and strength. Sealing, U-Values and interior comfort are all first-class, with additional options for neautral or colouredsolar control glass, switchable privacy glass, or self-cleaning glass.
Durable, low-maintenance finishes and robust weather protection even in driving heavy rain, make this system suitable for exposed rooflines and demanding environments—all with a sleek architectural finish.
.png)
Support and Customisation for Every Project
Available in bespoke sizes with black or grey powder-coated frames as standard—and custom RAL finishes on request—the Glideline Eaves Rooflight is flexible enough to meet any design brief. Glass panels are precision-cut and bonded to deliver a consistent, frameless look throughout.
We support installers, homeowners, and specifiers with straightforward configuration options, fast lead times, and dependable technical guidance to ensure each installation is as smooth and successful as the finished project, residential or commercial.
.png)
Engineered for Strength & Durability
Built to withstand harsh weather conditions, our Eaves Rooflights feature toughened, double or triple-glazed glass and strong aluminium frames. Designed for exceptional security and longevity, they offer high impact resistance while maintaining a minimalist, stylish aesthetic.
Technical specifications
General
Sightlines: 0-25mm
Glazing: 44mm max, 32mm min
Maximum dimensions: No max length, max width 1800mm
Colour options: Black 9005 or Grey 7016
Options
Solar control glazing
Frameless glass-to-glass joints
Self-cleaning glass
Test data
Double glazing: Uw from 1.4 (W/m²K)
Triple glazing: Uw ≥ 1.0 (W/m²K)
U-Value
Acoustic insulation: Rw up to 41 dB
Air permeability: Class 4
Water tightness: Class 7A
Wind resistance: Class C5
Security test: PAS24 passed

Colour Finishes
Available from Glideline
Powder Coating RAL Finish
Standard 7016M and 9005M, 9010G
Available in 150+ RAL finishes
Textured finish available
Split color for interior/exterior
Anodized aluminium
Class 15; 15-19 micrometer coating for external use as standard
Class 20; 20-24 micrometer coating for use in aggressive conditions, industrial areas and marine pollution
Class 20; 20-24 micrometer coating for use in aggressive conditions, industrial Silver brushed, silver rough brushed, bright silver, matte silver, brushed steel, rough brushed steel, brushed champagne re-polished, bright gold, rough brushed inox re-polished, brushed stainless steel, rough brushed ivory re-polished, brushed bronze, rough brushed bronze and re-polished, rough brushed copper re-polished, rough brushed Bordeaux re-polished, rough brushed green, rough brushed blue re-polished, rough brushed grey re-polished, matte black and marine pollution
Reviews
Thank you to the installers Joe and Luke for their hard work. It wasn't easy going up all the stairs but they were happy doing so and I couldn't be happier with the doors. Also Henry has been fantastic from sta…
Glideline installed 6 sets of sliding doors in our house. This was a major investment for us so we wanted it to be just right. David and all the team were friendly and helpful from start to finish. Henry was…
FAQs
How do I find pricing?
We price all of our flat roofs bespoke to each customer. This is because each aluminium rooflight is made specific to each customer’s requirements.
Are they environmentally friendly?
Aluminium is a sustainable resource that is also recyclable, being able to be reused time and time again. Because they’re energy efficient, they’ll also reduce the carbon footprint of your customer’s home.
Are they secure?
We have included several modern locking mechanisms in our aluminium rooflights to keep your project secure. Tamper proof fasteners will prevent intruders from attempting to break in through your flat roofs.
If we haven’t answered your question, Send us a message
